Electric/hyd. inground lift w/ 8.5" chrome pistons, wide drive-thru 3-Stage Arms and double telescoping screw pads. with Quick Cycle™ increasing rise (27 sec) & descent speed (approx. 17 sec). Packaged with BMC Bench Mounted Controls.



Features

• Ordering the lift with the above part number includes the integrated Bench Mount controls which are used for mounting the power unit inside of the workbench.
• Chrome Pistons -- benefits can extend the life of the piston, highly lubricous, ultra hard (harder than steel).
• Wide 87" drive-thru.
• Over 50% more bearing spread versus the completion, providing smooth and stable lifting.
• Three Stage arm design for maximum retraction.
• Quick Cycle™ increases rise (27 sec) & descent speed (approx. 17 sec)



Technical

Motor output	3HP	kW
Lifting-piston diameter	8-1/2	inch
Lifting/lowering time approx.	27 sec rise	s
Color	Choice of colors
Power supply	208/230 Single Phase	V/Hz/A
Extension height	73-3/4	inch
Operating pressure	75-125PSI	bar
Dimensions (L x W x H) rubber pad	6-1/2 - 8-3/4	inch
Support piston diameter	10,000	inch
Dimensions (L x W x H)	9.75 x 6 x 2.5 / 4.75 x 3 x 1	inch
Piston spacing	87 Drive-thru	inch
