Whatever your current level of productivity, CAR-O-LINER's BenchRack Series can help you surpass it. BenchRack is a marvel of function and design, with innovative features that allow you to complete each phase of the collision repair process more quickly, more easily and more profitably. SPECIFICATIONS: Platform length 13' 9", 16' 5", 18' 1", 20' 8" (4,200, 5,000, 5,500, 6,300 mm) Platform width3' 10" (1175 mm) Maximum height (floor to top of platform): 3' 11" (1190 mm) Maximum length (with draw aligner): Bench length + 3' 8" (1,120 mm) Maximum width (with draw aligner): 7' 6" (2,295 mm) Lift capacity (max. vehicle weight): 9,200 lbs. (4,200 kg) Pulling force per draw aligner: 10-ton ACCESSORIES: 10-ton Draw Aligner, 10-ton Hydraulic Pump, Hose and Cylinder Set, Ram Adapter, Power Unit, Hydraulic Oil, Bench Parts B106/B39BR Pillar Jack Kit, Double Grab Hook, 3/8" x 8' Chain with One Grab Hook



Features

• Available in four lengths to suit your specific repair needs.
• A revolutionary tilt-feature scissor lift, available on all BenchRack models, makes loading easier when approach space is limited.
• After loading, BenchRack's lightweight drive-on ramps can be easily removed to provide additional access to the vehicle and damage.
• The working height is infinitely variable to suit the technician's height preference up to an industry leading 47-1/4" with a 9,200 lb. weight capacity.
• Fast-anchoring pillar jacks, used to support vehicles during mounting, permit virtually any unibody or full frame car, pickup truck, sport utility or van to be clamped into place quickly and easily.
• Pull anywhere, 360° around the BenchRack, with hydraulic Draw Aligners that exert up to 10 tons of pulling force.
• Finely milled steel frame with stringent tolerances that result in a smooth, level surface and provide the to-the-millimeter accuracy CAR-O-LINER is famous for.
• Diamond-shaped cam locks provide a timesaving fast bolt system for anchoring and pulling components to be attached at any point along the rails.



Technical

Weight approx.	2,090 - 2,860	lbs
Power supply	110 / 60 single phase	V/Hz/A
