Fluid And Lube Handling



Graco 246781 Mini Fire-Ball ® 225 50:1 Pneumatic Grease Pump

USD $1,148.00

11-246781
Graco Inc.

Click to see additional Options / Models / Accessories Available
Options

Request a call



Click to view California Proposition 65 warning



For nearly 60 years, Graco Fire-Ball pumps have been a mainstay in the lubrication marketplace for durability and long life. Designed for the toughest applications, the Mini Fire-Ball 225 air-powered pumps are perfect for medium pressure, low volume applications, with continuous duty flow rates up to 1.5 lbs/minute.The pump featured is a 400 lb. pneumatic grease pump, typically handling grease up to NLGI #2 in automotive dealerships, fast lube centers, and service shops.



Features

  • Thick cast aluminum air motor housing with a corrosion- resistant design offer unmatched durability
  • Fewer moving parts in air motor assembly means less down time and low repair costs
  • In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life
  • Non-metallic poppet valves offer positive sealing performance, even with contaminated environments for long life without repair
  • 7 Year Warranty. See manufacturers website for details.
  • Approximate Free Flow Rate: @ 100 psi 1.5 lb./min (0.7 kg/min)
  • Approximate Air Use and Flow @ 100 psi (80 cpm): 9.3 scfm @ 0.62 lb./min (0..26 @ .28 kg/min)
  • Air Inlet: 3/4 in npt (f)
  • Fluid Outlet: 1/4 in npt (f)
  • Air Operation Range: 40-140 psi (3-10 bar)
  • Cycles per Pound/Kg: 130 cpp / 287 cpk
  • Wetted Parts: Steel, urethane, aluminum, buna-N, brass, ethylene, Delrin ®



Technical

Weight approx. 24.5 lbs
Dimensions (L x W x H) 52.8 x 9.6 x 10.8 inch



Options

11-246780 Graco 246780 Mini Fire-Ball ® 225 50:1 - 120 lb Pneumatic Grease Pump $1,018.00 Add to cart
